- Screen: 6.67" OLED - 1080 x 2400
- SoC: Qualcomm Snapdragon 8 Gen 2
- Camera: 3 (50 MP + 50 MP + 12 MP)
- Battery: 4600 mAh
- OS: Android 14
- Weight: 199 grams (7.02 oz)
Select the amount of RAM to evaluate performance more precisely
Compare Motorola Edge 40 Pro with other phones
Full specifications
Detailed specifications, tests, and benchmarks of the Motorola Edge 40 Pro
| Type |
OLED |
| Size |
6.67 inches |
| Resolution |
1080 x 2400 pixels |
| Aspect ratio |
20:9 |
| PPI |
394 ppi |
| Refresh rate |
165 Hz |
| Adaptive refresh rate |
Yes |
| Max rated brightness |
500 nits |
| Max rated brightness in HDR |
1100 nits |
| HDR support |
Yes, Dolby Vision |
| Touch sampling rate |
360 Hz |
| Screen protection |
Gorilla Glass Victus |
| Screen-to-body ratio |
90% |
| Display features |
- DCI-P3
- Always-On Display
- DC Dimming |
Display tests
| RGB color space |
147.3% |
| PWM |
235 Hz |
| Response time |
1 ms |
| Contrast |
β Infinity |
Peak brightness test (auto)
1053 nits
Sources:
NotebookCheck
[3]
| Height |
161.16 mm (6.34 inches) |
| Width |
74 mm (2.91 inches) |
| Thickness |
8.59 mm (0.34 inches) |
| Weight |
199 g (7.02 oz) |
| Waterproof |
IP68 |
| Advanced cooling |
Vapor chamber |
| Rear material |
Glass |
| Frame material |
Metal |
| Colors |
Black, Blue |
| Fingerprint scanner |
Yes, in-display |
Performance
Chipset specifications of the Motorola Edge 40 Pro
SoC
| Chipset |
Qualcomm Snapdragon 8 Gen 2 |
| Max clock |
3200 MHz |
| CPU cores |
8 (1 + 2 + 2 + 3) |
| Architecture |
- 3 cores at 2 GHz: Cortex-A510
- 2 cores at 2.8 GHz: Cortex-A710
- 2 cores at 2.8 GHz: Cortex-A715
- 1 core at 3.2 GHz: Cortex-X3 |
| L3 cache |
8 MB |
| Manufacturing |
TSMC |
| Lithography process |
4 nanometers |
| Neural processor (NPU) |
Hexagon |
GPU
| Graphics |
Adreno 740 |
| GPU shading units |
1536 |
| GPU clock |
680 MHz |
| FLOPS |
~2089 GFLOPS |
Benchmarks
Benchmark results of the Motorola Edge 40 Pro
Geekbench 6 (Single-Core)
1996
Geekbench 6 (Multi-Core)
5352
| Single-core score |
1996 |
| Multi-core score |
5352 |
AnTuTu Benchmark 11
1726358
| CPU |
587284 |
| GPU |
428539 |
| Memory |
296589 |
| UX |
413946 |
| Total score |
1726358 |
3DMark Steel Nomad Light
1094
| Stability |
79% |
| Graphics test |
8 FPS |
| Graphics score |
1094 |
| Stability |
81% |
| Graphics test |
20 FPS |
| Section 1 |
23 FPS |
| Section 2 |
20 FPS |
| Section 3 |
17 FPS |
| Graphics score |
5311 |
3DMark Wild Life Extreme
3631
| Stability |
71% |
| Graphics test |
21 FPS |
| Graphics score |
3631 |
Recent User Tests
The latest benchmark tests that have been submitted by users
RAM
| RAM size |
12 GB |
| Memory type |
LPDDR5X |
| Channels |
4 |
Storage
| Storage size |
256 GB |
| Storage type |
UFS 4.0 |
| Memory card |
No |
| Operating system |
Android 13 (Can be upgraded to Android 14) |
| ROM |
My UX |
| OS size |
26 GB |
| OS updates |
3 years |
| Security updates |
3 years |
| Capacity |
4600 mAh |
| Max charge power |
125 W |
| Battery type |
Li-Po |
| Replaceable |
No |
| Wireless charging |
Yes (15 W) |
| Reverse charging |
Yes, (wireless) |
| Fast charging |
Yes (83% in 15 min) |
| Full charging time |
0:23 hr |
Battery life tests
| Web browsing |
09:44 hr |
| Watching video |
14:09 hr |
| Gaming |
05:36 hr |
| Standby |
122 hr |
General battery life
24:27 hr
| Matrix |
50 megapixels |
| Image resolution |
8192 x 6144 |
| Zoom |
Optical, 2x |
| Flash |
Dual LED |
| Stabilization |
Optical |
| 8K video recording |
Up to 30FPS |
| 4K video recording |
Up to 60FPS |
| 1080p video recording |
Up to 60FPS |
| Slow motion |
960 FPS (1080p) |
| Angle of widest lens |
114Β° |
| Lenses |
1) Standard: 50 MP
2) Ultrawide: 50 MP
3) Telephoto: 12 MP
|
| Camera features |
- Bokeh mode
- Pro mode
- RAW support |
Standard lens
| Image resolution |
50 MP |
| Aperture |
f/1.8 |
| Sensor |
Omnivision OV50A |
| Sensor size |
1/1.55" (β 0.65 inch) |
| Pixel size |
1 micron |
| Autofocus |
Phase autofocus |
| Stabilization |
Optical |
Telephoto lens
| Image resolution |
12 MP |
| Aperture |
f/1.6 |
| Sensor |
Sony IMX663 |
| Sensor size |
1/2.93" (β 0.34 inch) |
| Pixel size |
1.22 micron |
| Stabilization |
Digital |
Ultra-wide lens
| Image resolution |
50 MP |
| Aperture |
f/2.2 |
| Sensor |
Samsung S5KJN1 |
| Sensor size |
1/2.76" (β 0.36 inch) |
| Pixel size |
0.64 micron |
| Stabilization |
Digital |
DxOMark main camera tests
Generic main camera score
130
| Megapixels |
60 megapixels |
| Image resolution |
4576 x 3296 |
| Aperture |
f/2.2 |
| Sensor |
Omnivision OV60A |
| Sensor size |
1/2.8" (β 0.36 inch) |
| Pixel size |
0.61 micron |
| Autofocus |
No |
| Stabilization |
Digital |
| Video resolution |
2160p (4K) at 60 FPS |
| Depth sensor (TOF 3D) |
No |
| Wi-Fi standard |
Wi-Fi 7 (802.11 a/b/g/n/ac/ax/be) |
| Wi-Fi features |
- Dual Band
- Wi-Fi MiMO
- Wi-Fi Direct
- Wi-Fi Hotspot
- Wi-Fi Display |
| Bluetooth version |
5.3 |
| Bluetooth features |
LE |
| USB type |
USB Type-C |
| USB version |
3.2 |
| USB features |
- Charging
- USB-Storage mode
- OTG |
| DisplayPort |
Yes, DP 1.4 |
| GPS |
GPS, GLONASS, Beidou, Galileo |
| NFC* |
Yes |
| Infrared port |
No |
Network
| Number of SIM* |
2 |
| Type of SIM card |
Nano |
| Multi SIM mode |
Standby |
| eSIM support* |
Yes |
| Hybrid slot |
No |
| LTE Cat* |
20 |
| 2G network |
GSM B2/3/5/8 |
| 3G network |
WCDMA B1/2/4/5/8 |
| 4G network |
LTE B1/2/3/4/5/7/8/12/13/17/18/19/20/25/26/28/32/38/39/40/41/42/43/48/66 |
| 5G support |
Yes |
| Speakers |
Stereo |
| Headphone audio jack |
No |
| FM radio |
No |
| Dolby Atmos |
Yes |
| Category |
Flagship |
| Announced |
April 2023 |
| Release date |
April 2023 |
| Launch price (MSRP) |
$899 |
| Successor |
- Motorola Edge 60 Pro |
| Sensors |
- Proximity sensor
- Gyroscope
- Accelerometer
- Ambient light sensor
- Compass
- Fingerprint |
| Bundled charger |
Yes, 125 W |
*Disclaimer! Some specifications of the Edge 40 Pro may differ by country or region
